Description
Proprietary wireless communication technology to transmit commands, alarms, and events.
Key features:
- Two-way communication.
- Advanced anti-sabotage.
- Block encryption featuring a dynamic key.
- Instant notifications.
- Remote control and configuration in Ajax apps.
Frequency bands
866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz
Depends on the sales region.
Maximum effective radiated power (ERP)
up to 20 mW
Automatic power control to reduce power consumption and radio interference.
Radio signal modulation
GFSK
Radio communication range
up to 1,700 m
Between the detector and a hub (or a range extender) in an open space.
Encrypted communication
All stored and transmitted data are protected by block encryption featuring a dynamic key.
Frequency hopping
To prevent radio interference and jamming.
 Wings communication technology
Proprietary wireless communication technology for uploading firmware updates.
Key features:
- Two-way communication.
- Advanced anti-sabotage.
- Block encryption featuring a dynamic key.
- Data packages reload in case of transmission errors.
Frequency bands
866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz
Depends on the sales region.
Radio communication range
up to 1,700 m
Between the detector and a hub (or a range extender) in an open space.
Encrypted communication
All stored and transmitted data are protected by block encryption featuring a dynamic key.
Frequency hopping
To prevent radio interference and jamming.
Detection
Sensitive elements
2 × PIR sensors
1 × K-band microwave sensor
K-band microwave sensor to prevent false alarms caused by thermal interference.
Operation frequency: 24 GHz.
Motion detection distance
up to 8–12 m
When installed at a height of 1–2.4 m. Adjusted with a slider at the detector enclosure.
Motion detection angles
horizontal: 8°
vertical: 85°/75°/15°
Depends on the installation height.
The angle is 85° or 75° at 2.4 m and 15° at 1 m.
Motion detection speed
0.3 to 2.0 m/s
The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility.
Sensitivity
3 levels
Adjusted by a PRO or a user with admin rights in the Ajax apps.
Pet immunity
height: up to 100 cm
weight: irrelevant
The detector should be installed at a height of 1 meter, and the slider on its enclosure should be set to the Pet position.
False alarm prevention
Dual motion detection technology
SmartDetect
Software algorithm.
Temperature compensation
Effective motion detection at temperatures from −25 °C to +60 °C.
Recommendations
It is recommended to install the detector at a height of:
- 2.4 m;
- 1 m when the Pet immune mode is enabled.
The device is designed for indoor and outdoor use.
Install the hood to protect the detector’s anti-masking system from rain and snow.
