Kingston KC600 2.5″ and mSATA SSD

Description

• Form Factor mSATA
• Interface SATA Rev. 3.0 (6Gb/s) – with backwards capability to SATA Rev 2.0 (3Gb/s)
• Capacities2 256GB, 512GB, 1024GB
• Controller SM2259
• NAND 3D TLC
• Encrypted XTS-AES 256-bit encryption
• Sequential Read/Write1 256GB — up to 550/500MB/s
• 512GB – 1024GB — up to 550/520MB/s
• Maximum 4K Read/Write1 up to 90,000/80,000 IOPS
• Power Consumption 08W Idle / 0.1W Avg / 1.2W (MAX) Read / 2.4W (MAX) Write
• Dimensions 8mm x2 9.85mm x 4.85mm
• Weight 7g
• Operating temperature 0°C~70°C
• Storage temperature -40°C~85°C
• Vibration operating 17G Peak (7-800Hz)
• Vibration non-operating 20G Peak (10-2000Hz)
• Life expectancy 2 millions hours MTBF
• Total Bytes Written (TBW)4 256GB — 150TB
• 512GB — 300TB
• 1024GB — 600TB
