MSI SPATIUM M570 PCIe 5.0 NVMe M.2 2TB HS

Description

• MODEL NAME SPATIUM M570 PCIe 5.0 NVMe M.2 HS
• CAPACITY           2TB
• CONTROLLER PHISON E26
• FLASH MEMORY 3D NAND
• DRAM CACHE 2GB LPDDR4       4GB LPDDR4
• FORM FACTOR 2 2280
• INTERFACE PCIe Gen5x4, NVMe 2.0
• COMPATIBILITY PCIe Gen5 / Gen4 / Gen3 / Gen2 / Gen1
• DIMENSIONS 00mm (L) x 22.00mm (W) x 3.5mm (H) (w/o heatsink)
• 40mm (L) x 23.00mm (W) x 20.40mm (H) (w/ heatsink)
• SEQUENTIAL READ UP TO (MB/S)    10,000
• SEQUENTIAL WRITE UP TO (MB/S)   10,000
• RANDOM READ 4KB UP TO (IOPS)   1,400,000
• RANDOM WRITE 4KB UP TO (IOPS) 1,500,000
• MAXIMUM OPERATING POWER (W) 10           11
• OPERATING TEMPERATURES 0°C – 70°C
• STORAGE TEMPERATURES -40°C – 85°C
• TERABYTES WRITTEN (TBW) 700        1400
• MEAN TIME BETWEEN FAILURE (MTBF) Up to 1,600,000 Hours
• ADVANCED FEATURES TRIM (Performance Optimization, OS Support required)
• SMART (Self-Monitoring, Analysis and Reporting Technology)
• LDPC (Low Density Parity Check) ECC Algorithm
• End to End Data Path Protection
• APST (Autonomous Power State Transition)
